Description
ICT A6E-18F0P-USD4 Bill Acceptor — 110V Pulse Validator with 800-Note Stacker
The ICT A6E-18F0P-USD4 is an A6E Series bill validator configured for United States currency handling in vending equipment and automated payment systems. This assembly operates from 110V AC power, uses the Pulse (STD Pulse) interface, and accepts denominations from $1-$20. E & D Trading supplies this new ICT unit as an authorized reseller for OEM builders, route operators, and service technicians requiring a fitted-bezel validator with high-volume note storage.
Specifications
- Manufacturer: ICT
- Model / SKU: A6E-18F0P-USD4
- Series: A6E
- Currency: United States
- Denomination acceptance: $1-$20
- Interface / protocol: Pulse (STD Pulse)
- Power supply: 110V AC
- Stacker capacity: 800 notes
- Bezel: Fitted
- Bill insertion: Four-way
- Accepted bill width: 60–67 mm
- Acceptance rate: 96% or higher
- Transaction time: Approximately 3 seconds
- Operating temperature: 0°C to 55°C
- Humidity: 30%–85% RH, non-condensing
- Condition: New
- Mounting hardware: Mounting kit not included
Compatible platforms
This validator is suited to vending machines and other automated payment equipment designed for 110V AC operation and a standard Pulse interface. The fitted bezel supports direct bill presentation at the machine fascia, while four-way insertion accommodates flexible note orientation during use.
Integration notes
The A6E-18F0P-USD4 includes auto-calibration and is configured for straightforward installation and service access. System designers should verify the host controller’s Pulse (STD Pulse) wiring and confirm that the cabinet provides compatible mounting provisions, since this version ships without a mounting kit. Environmental limits are 0°C to 55°C with 30%–85% RH non-condensing humidity.
Ordering & support
E & D Trading provides the ICT A6E-18F0P-USD4 for replacement, new equipment builds, and validator upgrades. Same-day quotes are available for volume orders, with freight coordination available for equipment deployments and service requirements.
Technical Specifications
| Brand | ICT |
| Model Series | A6 / A6E Series |
| Voltage | 110v |
| Supported Protocols | Pulse |
| Stacker Capacity | 800 Bills |
| Bezel Type | Fitted |
| Condition | New |
