Description
ICT A6E-18FCP-USD4 Bill Acceptor — 110V Pulse Validator with 800-Note Stacker
The ICT A6E-18FCP-USD4 is an A6E Series bill validator configured for United States currency in vending equipment and automated payment systems. Its 110V AC power configuration, STD Pulse interface, fitted bezel, and 800-note stacker support straightforward integration into compatible machines. E & D Trading supplies this new ICT unit to OEM builders, route operators, and service technicians requiring a defined replacement or installation-ready bill acceptance assembly.
Specifications
- Manufacturer: ICT
- Model / SKU: A6E-18FCP-USD4
- Series: A6E
- Currency: United States currency
- Denomination acceptance: $1-$20
- Power supply: 110V AC
- Interface / protocol: Pulse (STD Pulse)
- Stacker capacity: 800 notes
- Bezel: Fitted
- Mounting hardware: Cover mounting kit included
- Bill insertion: Four-way
- Bill width accepted: 60–67 mm
- Acceptance rate: 96% or higher
- Transaction time: Approximately 3 seconds
- Calibration: Automatic
- Operating temperature: 0°C to 55°C
- Humidity: 30%–85% RH, non-condensing
- Condition: New
Compatible platforms
This validator is intended for compatible vending machines and automated payment equipment that use 110V AC input and the Pulse (STD Pulse) communication format. The fitted bezel supports front-access bill entry, while the 800-note stacker provides stored-note capacity for higher-volume service routes.
Integration notes
Confirm the host machine’s voltage, Pulse interface wiring, cabinet clearance, and mounting provisions before installation. The unit accepts notes from four directions and supports 60–67 mm bill widths. Automatic calibration, the supplied cover mounting kit, and accessible installation and maintenance features help simplify field servicing. Operating conditions should remain within 0°C to 55°C and 30%–85% relative humidity without condensation.
Ordering & support
E & D Trading is an authorized distributor and reseller for ICT payment equipment. The A6E-18FCP-USD4 is available for individual machine builds, replacements, and route deployments. E & D Trading provides same-day quotes on volume requirements and can coordinate freight for larger orders.
Technical Specifications
| Brand | ICT |
| Voltage | 110v |
| Supported Protocols | Pulse |
| Stacker Capacity | 800 Bills |
| Bezel Type | Fitted |
| Condition | New |
