Description
ICT A6E-25F0P-USD4 Bill Acceptor — 12V Pulse Validator with 500-Note Stacker
The ICT A6E-25F0P-USD4 is an ICT A6E Series bill validator configured for United States currency and USD $1-$20 denomination acceptance. It operates from a 12V DC supply and uses the STD Pulse interface for integration with compatible vending and automated payment equipment. E & D Trading supplies this new unit as an authorized ICT reseller for OEM builders, equipment integrators, and route operators requiring a fitted-bezel validator with on-board note storage.
Specifications
- Manufacturer: ICT
- Model / SKU: A6E-25F0P-USD4
- Series: ICT A6E Series
- Currency: United States currency
- Denomination acceptance: USD $1-$20
- Interface / protocol: Pulse (STD Pulse)
- Voltage: 12V DC
- Stacker capacity: 500 notes
- Bezel: Fitted
- Bill insertion: Four-way
- Accepted bill width: 60–67 mm
- Acceptance rate: 96% or higher
- Transaction time: Approximately 3 seconds
- Calibration: Automatic calibration system
- Operating temperature: 0°C to 55°C
- Humidity: 30%–85% RH, non-condensing
- Condition: New
- Included configuration: Fitted bezel; mounting kit not included
Compatible platforms
This validator is intended for vending machines, automated payment systems, and other equipment designed to communicate through a standard Pulse interface. The four-way note path supports flexible cabinet and control-panel layouts, while the 500-note stacker provides collected-note capacity for unattended operation.
Integration notes
Confirm that the host controller is configured for STD Pulse signaling and that the equipment provides the required 12V DC input before installation. The unit accepts notes measuring 60–67 mm wide and should be installed in an environment within the stated temperature and non-condensing humidity limits. A mounting kit is not supplied, so the installer must provide mounting hardware appropriate to the cabinet or enclosure. Routine service access is supported by the automatic calibration system and the validator’s installation and maintenance design.
Ordering & support
E & D Trading provides the ICT A6E-25F0P-USD4 for replacement, new-build, and retrofit requirements. Volume customers can request same-day quotes, and E & D Trading can coordinate freight for equipment projects and multi-unit orders.
Technical Specifications
| Brand | ICT |
| Model Series | A6 / A6E Series |
| Voltage | 12v |
| Supported Protocols | Pulse |
| Stacker Capacity | 500 Bills |
| Bezel Type | Fitted |
| Condition | New |
