Description
ICT NBA-E1AR-5BU-MX5 Bill Validator — Pulse MXN Acceptor
The ICT NBA-E1AR-5BU-MX5 is an NBA Series bill validator configured for 12V–24V DC operation, Pulse communication, and Mexican peso (MXN) currency acceptance. Its 500-note single-lock cashbox, four-way insertion, and IR Anti-fish protection suit vending, gaming, automated payment, and other unattended equipment. E & D Trading supplies this ICT validator as an authorized distributor for OEM builders, integrators, route operators, and service technicians requiring a standard Pulse interface without barcode or RFID functions.
Specifications
- Manufacturer: ICT
- Model / SKU: NBA-E1AR-5BU-MX5
- Currency: Mexican peso (MXN)
- Denominations accepted: MXP: 20, 50, 100, 200, 500
- Interface / protocol: Pulse
- Power supply: 12V–24V DC; operating range 11.4V–25.2V DC
- Cashbox: Single-lock, approximately 500 bills
- Accepted bill width: 62mm–83mm
- Acceptance rate: 96% or higher
- Transaction time: Approximately 5 seconds to stack
- Security: IR Anti-fish (anti-string) technology and optical bill detection
- Insertion: Four-way bill entry with automatic bill centering
- Included harness: WEL-RNJ11
- Operating temperature: 0°C to 50°C
- Humidity: 30%–95% RH, non-condensing
- Recycler: FALSE
Compatible platforms
This validator fits compatible vending machines, gaming equipment, kiosks, and automated payment systems that provide 12V–24V DC power and a Pulse protocol input. The MXN configuration is intended for installations using the listed Mexican peso denominations.
Integration notes
The supplied WEL-RNJ11 harness supports installation where the equipment wiring matches the validator configuration. Confirm system voltage, Pulse signal requirements, bill path clearance, and cashbox access before deployment. This NBA-E1AR-5BU-MX5 does not provide barcode or RFID support; applications requiring either function need a different NBA configuration. Routine service access is supported by the removable single-lock cashbox and straightforward bill path.
Ordering & support
E & D Trading provides the ICT NBA-E1AR-5BU-MX5 for replacement, retrofit, and new equipment builds. Same-day quotes are available for volume requirements, with freight coordination available for project and route deployments. Provide the machine model and existing interface details when requesting fitment assistance.
Technical Specifications
| Brand | ICT |
| Model Series | NBA Series |
| Voltage | 12v24v |
| Supported Protocols | Pulse |
| Stacker Capacity | 500 Bills |
| Condition | New |
