Description
ICT V6E-38F0M-USD4-T# Bill Validator — 24V MDB Validator with 800-Note Stacker
The ICT V6E-38F0M-USD4-T# is a V6E Series bill validator configured for 24V DC vending and automated payment equipment. It accepts United States denominations from $1 through $20, communicates through MDB, and uses an 800-note stacker for cashbox storage. E & D Trading supplies this new ICT unit to OEM builders, Touchtunes technicians, vending operators, and route-service teams requiring a fitted-bezel validator in a defined Touchtunes configuration.
Specifications
- Manufacturer: ICT
- Model / SKU: V6E-38F0M-USD4-T#
- Series: ICT V6E Series
- Interface: MDB
- Voltage: 24V DC
- Currency: United States
- Denomination acceptance: $1–$20
- Stacker capacity: 800 notes
- Bezel: Fitted
- Bill entry: Four-way insertion
- Accepted bill width: 60–67 mm
- Acceptance rate: 96% or higher
- Transaction time: Approximately 3 seconds
- Calibration: Automatic calibration system
- Recycler: No
- Operating temperature: 0°C to 55°C
- Storage temperature: -30°C to 70°C
- Humidity: 30%–85% RH, non-condensing
- Condition: New
Fitment
This validator is intended for MDB-equipped vending machines and automated payment systems, including Touchtunes equipment using the specified fitted-bezel configuration. Four-way note entry supports flexible cabinet installation and routine operator use.
Integration notes
The assembly ships with the bezel fitted but does not include a mounting kit or harness. The Touchtunes configuration therefore requires the installer to use the appropriate existing or separately sourced mounting hardware and wiring. Allow the unit to operate within the stated temperature and non-condensing humidity limits. Its automatic calibration function supports service installation and ongoing bill-recognition performance.
Ordering & support
E & D Trading is an authorized ICT distributor and reseller. The V6E-38F0M-USD4-T# is available for replacement, retrofit, and equipment-build requirements. E & D Trading provides same-day volume quotes and can coordinate freight for commercial orders.
Technical Specifications
| Brand | ICT |
| Model Series | V6 / V6E Series |
| Voltage | 24v |
| Supported Protocols | MDB |
| Stacker Capacity | 800 Bills |
| Bezel Type | Fitted |
| Condition | New |
