MEI CX-25 3 Bin In-Line Coin Dispenser Full Unit
The MEI CX-25 3 Bin In-Line Coin Dispenser Full Unit is a high-capacity coin dispensing assembly for OEM-integrated self-service equipment. Its three-bin configuration supports coin handling in kiosks, self-checkout systems, ATMs, and financial service equipment where dependable payout and reduced refill frequency are required. E & D Trading supplies this Crane MEI unit to integrators, route operators, and service teams requiring a factory-configured dispenser with USB and RS232 connectivity.
Specifications
- Series: MEI CX-25
- Product type: Coin Dispenser Full Unit
- Configuration: 3-Bin In-Line
- Coin speed: Depends on bin configuration
- Coin capacity: Varies by configuration
- Dimensions (H × W × D): 231.1 × 175.26 × 264.1 mm (without cup)
- Interfaces supported: RS232 Serial Port and USB Connectivity
- Power requirements: 24V DC
- Maximum current: 1.7 Amps
- External switching power supply: Single 24V DC
- Transaction control: Firmware-based transaction logging
- Bin handling: Tilting bins for loading and emptying
- Compliance: CE, UL, CUL Listed, RoHS
- Condition: New
- Currency type: Coins
- Brand: Crane MEI
Compatible platforms
This dispenser is configured for host-machine installation in self-service kiosks, self-checkout systems, ATMs, and financial service applications. The compact in-line format is suited to equipment layouts that require multiple coin denominations or higher available coin storage within a single dispensing assembly.
Integration notes
The CX-25 requires a host machine and operates from 24V DC, with a maximum current draw of 1.7 Amps. Integrators should confirm the selected bin configuration, available coin capacity, coin speed, cabinet clearance, and host communication requirements before installation. Firmware-based transaction logging supports transaction control and enhanced security, while the tilting bins simplify cash loading, emptying, and routine cash management. A single 24V DC external switching power supply is specified.
Ordering & support
E & D Trading is an authorized distributor for the Crane MEI CX-25 platform and provides this new full-unit assembly for OEM builds, replacements, and service inventory. Contact E & D Trading for same-day volume quotes, application review, and freight coordination.
Technical Specifications
| Brand | Crane MEI |
| Condition | New |
