MEI CX-25 8 Bin Coin Dispenser Full Unit — High-Capacity Banking and Self-Service Coin Module
The MEI CX-25 8 Bin Coin Dispenser Full Unit is an eight-bin coin dispensing assembly for OEM builders, financial-service equipment manufacturers, and route operators. Its high-capacity hopper configuration helps reduce refill frequency, while firmware-based transaction logging retains transaction history in firmware memory. E & D Trading supplies this MEI unit as an authorized reseller for qualified host-machine integration and replacement requirements.
Specifications
- Manufacturer: MEI / Crane MEI
- Series: MEI CX-25
- SKU: cx-25-8-bin
- Product type: Coin Dispenser Full Unit
- Configuration: 8-bin system
- Coin speed: Depends on bin configuration
- Coin capacity: Varies by configuration
- Dimensions: 231.1 × 348.74 × 344.42 mm (without cup)
- Interfaces: RS232 serial port and USB connectivity
- Power: Direct connection, 24V DC
- Maximum current: 1.7 Amps
- External switching power supply: Single 24V DC
- Cash handling: Tilting bins support loading and emptying; dispensing configuration is flexible
- Logging: Firmware-based transaction logging with history stored in firmware memory
- Compliance: CE, UL, CUL Listed, RoHS
- Condition: New
- Currency type: Coins
Compatible platforms
The CX-25 is configured for banking equipment, financial service applications, self-service machines, and self-checkout systems. It requires installation in a compatible host machine and is intended for high-cash-volume environments where long operational life and simplified cash management are important.
Integration notes
Plan the host installation around the stated 231.1 × 348.74 × 344.42 mm dimensions and the unit's 24V DC power requirements. The maximum current draw is 1.7 Amps. Confirm the host controller supports the RS232 serial port or USB connection before deployment. Bin arrangement affects both coin speed and total coin capacity.
Ordering & support
E & D Trading provides the MEI CX-25 8-bin unit to OEM integrators, financial equipment service teams, and route operators. Contact E & D Trading for same-day quotes on volume requirements and freight coordination.
Technical Specifications
| Brand | Crane MEI |
| Condition | New |
