MEI Talos T611-U7EUS Amusement Bill Acceptor

MEI Talos T611-U7EUS Amusement Bill Acceptor

The MEI Talos T611-U7EUS is a Crane MEI Talos T6 Series validator configured for U.S. currency and 110 V AC legacy equipment. Its VFM front-mount bezel, upward-facing 700-note stacker, and optical validation package suit amusement machines, vending equipment, and kiosks using AC-powered interfaces. E & D Trading supplies this new unit as an authorized Crane MEI distributor and reseller for OEM builders, route operators, and service technicians.

Specifications

• Currency: U.S. Dollar (USD)
• Denominations: $1, $5, $10, and $20; $50 and $100 notes are not accepted
• Interface: 110 V AC pulse / parallel / legacy
• Operating voltage: 110 V AC ±10%
• Bezel: VFM compact front-mount bezel
• Stacker: Up-Stacker with a 700-note interchangeable cassette
• Insertion: Four-way bill acceptance, allowing notes in any orientation
• Validation: Optical security system with anti-counterfeit and anti-stringing protection
• Operating temperature: 0 °C to 50 °C (32 °F to 122 °F)
• Firmware: Upgradeable through USB or a handheld programmer
• Service: Quick-release stacker supports tool-free maintenance
• Brand and condition: Crane MEI, new

Cross-reference

This T6-series validator is the direct replacement for the AE2611-U7EUS. The T611-U7EUS uses the T6 platform associated with AE26xx validators and retains the 110 V AC configuration required by compatible legacy systems.

Compatible platforms

The unit is configured for amusement applications under market code 6 (Amusement), as well as compatible vending machines and kiosks that use a 110 V AC pulse or parallel interface. Its code identifies a Talos T6 platform, VFM bezel, 110 V AC power configuration, U7 upward stacker with 700-note capacity, and EUS U.S. E-series mainboard and Talos firmware configuration.

Integration notes

Confirm cabinet wiring, connector arrangement, mounting clearance, and legacy interface requirements before installation. The validator accepts only $1, $5, $10, and $20 U.S. notes; applications requiring $50 or $100 acceptance should use a T8-series model. The removable cassette and USB or handheld-programmer firmware access simplify field service.

Ordering & support

E & D Trading provides the MEI Talos T611-U7EUS with distributor support for replacement, retrofit, and production requirements. Same-day volume quotes and freight coordination are available, along with repair support for bill acceptor installations.
